Thermography Gallery

The following thumbnail photos illustrate thermal images of electrical, process and roofing problems. Click on the thumbnail for enlargement of the image. Contact us for more details.

: Heat loss in metal wall construction.

: Loose lug connection of a high voltage switch, photo courtesy of Flir Systems Inc.

: Loose connection from a breaker to a fuse on both first and second phases, photo courtesy of Flir Systems Inc.

: First phase fuse top clip is loose, photo courtesy of Flir Systems Inc.

: First phase fuse clip and bolts are loose on a breaker, photo courtesy of Flir Systems Inc.

: Third phase fuse top clip and lug for disconnect is defective, photo courtesy of Flir Systems Inc.

: Third phase fuse and lug connection on a breaker is loose, photo courtesy of Flir Systems Inc.

: Transformer bushing connection is loose internally, photo courtesy of Flir Systems Inc.

: Refractory lining on a rotating kiln is defective, photo courtesy of Flir Systems Inc.

: Defective 15 amp breaker found in a lighting panel.

: Poor connection at the jaws of a switch on a high voltage tower.

: Heat loss concrete insulated panel.

: Loose fuse holder on a high voltage fuse, photo courtesy of Flir Systems Inc.

: Wet fibreboard insulation panel on a flat roof, photo courtesy of Flir Systems Inc.

: Wet insulation found adjacent to a roof drain.

: Wet fibrous glass insulation panel found in a roof.

: Electrical disconnect panel, thermal image of the 1st phase incoming lug connection found to be loose.

: Evaluation of refractory lining in a process kiln furnace.

: Evaluation of refractory lining for a process gas breaching.

: Infrared image of defective refractory lining for process vessels and breaching.

: Defective refractory lining for an incinerator.

: Loose lug connection on a starter in an electrical panel.

: Poor seals around doorway.

: Defective knife blades in an electrical disconnect.

: Loose fuse clips in an electrical panel.

: Loose lug connection at top of an electrical breaker.

: Defective elbow and bushing for a high voltage pad mount transformer.

: Wet insulation found in a built up flat roof system.

: Loose lug connection on a high voltage switch.

: Defective high voltage switch. Poor closure at jaws of switch.

: Heat loss around access doors on a gas breaching.

: Refractory lining conditions for a process furnace and associated gas flue.

: Heat loss for a boiler side wall casing.

: Heat loss to due poor seals in walls.

: Internal IR scan of a refinery process heater tubes.

: Coke located on bottom tubes (light gray area) in a process refinery heater.

: Cold air infiltration at doors.

: Heat loss door entrance seals.

: Wet insulation in a built up roof.

: Wet insulation in flat roofs.

: Refractory lining failure in a sulphur furnace.

: Loose wire connection in an electrical panel.

: Loose wire connections at fuse holders.

: Loose termination of control wiring.

: Missing insulation in walls.

: Wet insulation in roof.

: Heat loss at shipping door seals.

: Heat loss from single pane windows in a building.

: Thermogram of wet insulation on a flat built up roof. Photo courtesy on Infraspection Institute.

: Heat loss at roof line flashing.

: Sample of missing insulation in plant wall.

: Heat loss at window frames and seals.

: Insulation missing in plant wall system.

: Heat loss from poor window seals.

: Thermogram of wet insulation area on a roof adjacent to a soil vent. Photo courtesy of Flir Systems Inc.

: Verification of moisture content in insulation during core test procedures and infrared scanning using a Delmhorst moisture probe.

: Infrared photo of a loose jumper connection on a high voltage system, phost courtesy of Flir Systems Inc.
